Spandex Machine

  • Spandex Yarn Melt Spinning Machine
Spandex Yarn Melt Spinning Machine

Spandex Yarn Melt Spinning Machine

  • Port: Shanghai China
  • Certification: CE,ISO,UL,QS
  • Brand: JWELL
  • Material: TPU chips
  • Description: JWELL Spandex Yarn Melt Spinning Machine, spandex machine
  • INQUIRY   EMAIL

JWELL Spandex (TPU) Yarn Melt Spinning machine

Application:

Mainly used for spandex melt spinning.

This machine adopts the equipment manufactured by JJWELL itself and the most advanced technology

■Adopting specialized spandex screw extruder and A.C inverter drive system

■Unique crossing additive adding system with the patent in China

■New type spin beam, parallel queching system and high precision planetary pumps

■Finish oil spraying and driving system which are suitable for spandex yarn

■Imported high precision inverter with imported high precision temperature controling meter

■Specialized manual or fully automatic spandex winder

spandex machine

Technical parameter:

  • Spinning area: 15D 20D 30D 40D

  •

  • Mechanical Speed: 1000m/min

  •

  • Positions: 8 or 10

  •

  • Site distance: 600,700,800 mm

  •

  • Box Type: independent, parallel spinning and winding

  •

  • Component form: bottom-mounted

  •

  • No of Ends: 10 or 16 Ends

spandex machine

New Products Introduction:

T400 New process technology

Fully automatic high-speed precision control Winder

Special Extruder for modified chips

Interconnected control system

Hot Roller System for differential spinning



Product Overview:

Direct Spinning

PET (polyester)- POY/FDY

PA6(nylon)- POY/FDY

PET Recycling-POY Bottle flakes

PP (polypropylene) FDY/BCF

Spandex yarn

Industry Yarn

T400/T8/ITY/SPH Bi-component

PET/PA6 Multi-composite spinning

Microdenier POY

BCF line

Old Spinning project Modification

spandex machine


Product Description


MaterialPET/ PA6 / PA66 / spandex / PP chips, PET flakes
Denier(D) Range50D-500D (customized)
NO. OF Holes (filament)24F 36F 48F 72F 96F 144F 228F 288F(customized)
ProductionPOY/ FDY/BCF/Industry Yarn/ Micro denier (customized)
Process speedPET POY:2800-3500m/min
PET FDY:2600-4500m/min
NO. of Positions 6 / 8 /10 / 12 positions(customized)
NO. of ENDS 8 /10 / 12 ends(customized)
WindersAutomatic
Grade class rateup to grade class rate ≥98%,first class rate ≥95%,full package rate≥90%
