POY spinning machine Performance and Advantages
POY Spinning Machine is mainly used for spinning 30-330dtex polyester POY.
Adopts LTM type pin screw, domestic-made continuous melt CPF, thus extend the service life of spin packs.
Both top-mounted and bottom-mounted high-pressure rectangular and cup-shaped spin packs are available.
Unique planetary spinning pump and separately driving finish oil pump.
Evo and cross quench system with equably and stable flowing speed.
Individually controlled, imported inverter and components.
New adjustment GR, imported inverter and components
New Products Introduction
T400 New process technology
Fully automatic high-speed precision control Winder
Special Extruder for modified chips
Interconnected control system
Hot Roller System for differential spinning
Types of JWELL Yarn Spinning Machine
Direct Spinning
PET (polyester)- POY/FDY
PA6(nylon)- POY/FDY
PET Recycling-POY Bottle flakes
PP (polypropylene) FDY/BCF
Spandex yarn
Industry Yarn
T400/T8/ITY/SPH Bi-component
PET/PA6 Multi-compositespinning
Microdenier POY
BCF line
Old Spinning project Modification
Specification of POY Spinning Machine
| Material | PET/ PA6 / PA66 / spandex / PP chips, PET flakes |
| Denier(D) Range | 50D-500D (customized) |
| NO. OF Holes (filament) | 24F 36F 48F 72F 96F 144F 228F 288F(customized) |
| Production | POY/ FDY/BCF/Industry Yarn/ Micro denier (customized) |
| Process speed | PET POY:2800-3500m/min PET FDY:2600-4500m/min |
| NO. of Positions | 6 / 8 /10 / 12 positions(customized) |
| NO. of ENDS | 8 /10 / 12 ends(customized) |
| Winders | Automatic |
| Grade class rate | up to grade class rate ≥98%,first class rate ≥95%,full package rate≥90% |
