Nylon FDY spinning machine Performance and Advantages
FDY Spinning Machine is mainly used for chips spinning of PA6 and PA66
Uniform and stable quenching chamber system, for the better yarn evenness.
Finishing spray system for super microfilament and universal oil wheel feeding
system.
Imported high precision inverter equiped with high precision RKC with setting,
temperature controlling, monitoring and recording functions.
Equipped with JW series precision winding and automatic winder produced
by Shanghai Jwell Chemical Fiber Machinery Co.,Ltd, high successfully of
doffing, fineness of yarn shape, and good function of unwinding.
New Yarn Spinning Machine Introduction
T400 New process technology
Fully automatic high-speed precision control Winder
Special Extruder for modified chips
Interconnected control system
Hot Roller System for differential spinning
JWELL Yarn Spinning Machine Overview
Direct Spinning
PET (polyester)- POY/FDY
PA6(nylon)- POY/FDY
PET Recycling-POY Bottle flakes
PP (polypropylene) FDY/BCF
Spandex yarn
Industry Yarn
T400/T8/ITY/SPH Bi-component
PET/PA6 Multi-composite spinning
Microdenier POY
BCF line
Old Spinning project Modification
Specifications of JWELL Nylon FDY Spinning Machine
| Material | PET/ PA6 / PA66 / spandex / PP chips, PET flakes |
| Denier(D) Range | 50D-600D (customized) |
| NO. OF Holes (filament) | 24F 36F 48F 72F 96F 144F 228F 288F(customized) |
| Production | POY/ FDY/stry Yarn/ Micro denier (customized)BCF/Indu |
| Process speed | PET POY:2800-3500m/min |
| PET FDY:2600-4500m/min | |
| NO. of Positions | 6 / 8 /10 / 12 positions(customized) |
| NO. of ENDS | 8 /10 / 12 ends(customized) |
| Automatic Winders | JWA1380/JWA1500/JWA1680/ JWA1800 |
| Grade class rate | up to grade class rate ≥98%,first class rate ≥95%,full package rate≥90% |
All Key parts: screw & barrel, and downstream equipment are made by JWELL factory!
